Siemens RCR10/433 User Manual

5/12
Siem ens Room temperature controllers CE1N3072en
Building Technologies 2014-04-04
Mechanical design
The RCR10/433 is in a plastic housing with LEDs and buttons.
Signal display LED
OVERRIDE button
LEARN button
Relay display LED
OVERRIDE & LEARN
buttons together = RESET
function
RCR10/433
The RDJ10RF is located in a plastic housing. The buttons are visible on the rear when
you remove the baseplate.
Test button
Learn button
Test & Learn button
together = RESET-
function
RDJ10RF

Siemens RCR10/433 Specifications

General

Operating Voltage	230 V AC
Temperature Setting Range	5°C to 30°C
Control Type	On/Off
Type	Room Thermostat
Power Supply	230 V AC
Protection Class	IP30
Frequency	50 Hz
Mounting Type	Wall
Switching Current	10 (4) A
Accuracy	±1°C
