6/8
Siemens Building Technologies Room temperature controllers CE1N3035en
HVAC Products 25.09.2003
Technical data
Operating voltage
• RDE10 at L and N AC 230 V +10/-15 %
• RDE10.1 DC 3 V (2 x 1.5 V AAA Alkaline - batteries)
Frequency (RDE10) 50 or 60 Hz
Power consumption (RDE10) 4VA
Battery life (RDE10.1) > 1 years (AAA Alkaline - batteries)
Control output Q12 (N.C. contact)
Rating RDE10 (AC 230 V) max. 5 A
Rating RDE10.1 (AC 24…250 V) max. 5(2) A
Control output Q14 (N.O. contact)
Rating RDE10 (AC 230 V) max. 5 A
Rating RDE10.1 (AC 24…250 V) max. 5(2) A
Switching differential SD 1 K
Setpoint setting range 5…35 °C (normal operation)
0 (OFF) and 5…35 °C (energy saving mode)
Factory setting normal operation 20 °C
Factory setting energy saving mode 8 °C
Resolution of settings and displays
Setpoints 0.5 °C
Switching times 60 min
Actual value displays 0.5 °C
Time of day displays 1 min
Operation to IEC 721-3-3
Climatic conditions class 3K5
Temperature 0…+50 °C
Humidity <95 % r. h.
Transport to IEC 721-3-2
Climatic conditions class 2K3
Temperature -25…+60 °C
Humidity <95 % r. h.
Mechanical conditions class 2M2
Storage to IEC 721-3-1
Climatic conditions class 1K3
Temperature -25…+60 °C
Humidity <95 % r. h.
conformity to
EMC directive 89/336/EEC
Low voltage directive 73/23/EEC and 93/68/EEC
N474
C-Tick conformity to
EMC emission standard
AS/NSZ 4251.1:1994
Product standards
Automatic electrical controls for EN 60 730 – 1 and
household and similar use EN 60 730 – 2 - 9
Electromagnetic compatibility
Emissions EN 50 081-1
Immunity EN 50 082-1
Safety class II to EN 60730
Pollution class normal
Degree of protection of housing IP30 to EN 60529
Power supply
Control outputs
Functional data
Environmental conditions
Norms and standards
