Siemens RDE10 Series User Manual

8/8
Siemens Building Technologies Room temperature controllers CE1N3035en
HVAC Products 25.09.2003
T
N1
Y1
2222S03
M1
Room temperature controller with direct
control of a heating circuit pump (precontrol
by manual mixing valve)
F1 Thermal reset limit thermostat
F2 Safety limit thermostat
M1 Circulating pump
N1 RDE10... room temperatures controller
Y1 3-port valve with manual adjustment
Y2 Magnetic valve
Dimensions
96
119
23,8
3035M01
89,45
4
3035M02
28 28
28
28
26
30
3530
11,8
112,3
4
Controller
Baseplate
 2003 Siemens Building Technologies AG Subject to alteration
