4/4 Operating Instructions CB1B1422en_01 / 2013-03-08 Siemens Building Technologies
Do you want to change the parameters?
+
–
ok
mode
If you want to change control parameters, proceed as
follows:
• Press + and – simultaneously for 5 seconds
• Release them and parameter "P01" is displayed
on the bottom segment
• Press + or – to scroll to the parameter that
needs to be adjusted
• Press ok to select this parameter
• Press + or – to adjust the value
• Press ok to confirm the adjusted value
• Press mode to exit the parameters without
saving or wait for the program to exit
automatically
Parameter list
Parameter
no.
Description Setting range (default)
P01 Time format 1 = 24:00 hours (default)
2 = 12:00 AM/PM
P02 Selection of °C or °F 1 = °C (default)
2 = °F
P03 Standard
temperature display
1 = room temperature
(default)
2 = setpoint
P04 Temperature sensor
calibration
-3…3 °C
Step 0.5 °C
(-6…6 °F, step 1 °F)
Default: 0 °C
P06 Comfort setpoint
lock
0 = OFF (default)
1 = ON  locked
according to setting in
permanent temperature
setpoint
P08 Economy setpoint
lock
0 = OFF (default)
1 = ON  locked
according to setting in
permanent temperature
setpoint
P09 Buzzer 0 = OFF
1 = ON (default)
P10 Show frost protection
icon
0 = OFF (default)
1 = ON
P11 Time switch type for
auto timer
0 = Individual Days
(default)
1 = All 7 days
2 = 5/2 days
P12 Periodic pump run 0 = OFF (default)
1 = ON
P14 X1 External input
(only for RDE100.1)
0 = No input
1 = External sensor
2 = Digital Input
P15 Temperature
limitation (only for
RDE100.1)
0 = OFF (default)
1 = ON
P16 Max limitation
temperature for
underfloor heating
(only for RDE100.1)
35…60 °C, step 1 °C or
95…140 °F, step 1 °F
Default: 55 °C
P17 Window contact
features (only for
RDE 100.1)
0 = Normally Open
Contact (default)
1 = Normally Closed
Contact
P21 Button scanning rate
for the capacitive
buttons
(RDE100.1 only)
Note: a shorter
scanning rate means
shorter battery life.
0.2 = 0.25 s
0.5 = 0.5 s
1.0 = 1.0 s (default)
1.5 = 1.5 s
P22 Reload factory
settings
0 = OFF (default)
1 = reload
P23 Software version
information
No adjustment possible

Siemens RDE100 Specifications

General

Type	Room Thermostat
Temperature Range	5°C to 30°C
Display	LCD
Control Type	Electronic
Protection Class	IP30
Mounting	Wall mounting
Output	Relay
Ambient Temperature Range	0°C to 50°C
Operating Voltage	3V (from batteries)
