54 / 62
Siemens RDF302 Basic documentation CE1P3079en
Smart Infrastructure 2022-06-17
1 Operating mode
Protection
Comfort
Economy
2 Displays room temperature,
setpoints and control parameters
Symbol indicates current room
temperature
3 Fan mode
Auto fan active
Fan speed
low, medium, high
4 Indicates fault or reminder
5 Heating/cooling mode
Cooling
Heating
Electrical heater active
6 Condensation in room (dew point
sensor active)
7 Additional user information, like
outdoor temperature
( )
or time
from Modbus (selectable via
parameters)
8 Key lock active
The device is considered electrical and electronic equipment for disposal in terms
of the applicable European Directive and may not be disposed of as domestic
garbage.
• Dispose of the device through channels provided for this purpose.
• Comply with all local and currently applicable laws and regulations.
