Description of applications
The RDG/RDF thermostats cover the following applications:
FCUs via ON/OFF or modulating control outputs:
– 2-pipe system
– 2-pipe system with electric heater
– 2-pipe system and radiator/fl oor heating
1
– 4-pipe system
– 4-pipe system with electric heater
1
– 2-stage heating or cooling system
1
VAV systems via ON/OFF or modulating control outputs:
– Single-duct system
– Single-duct system with electric heater
– Single-duct system and radiator/fl oor heating
1
– Single-duct system with heating/cooling coil
1
Chilled/heated ceilings (or radiators) via ON/OFF or modulating control outputs:
– Chilled/heated ceiling
– Chilled/heated ceiling with electric heater
– Chilled/heated ceiling and radiator/fl oor heating
1
– Chilled/heated ceiling, 2-stage heating or cooling
1
