Siemens RDG100…/RDG110…/RDG140.../RDG160… Basic Documentation CE1P3076.en
Building Technologies Mechanical design 28 May 2009
7 Mechanical design
7.1 General
The room thermostat consists of 2 sections:
• Plastic housing which accommodates the electronics, the operating elements
and the temperature sensor
• Mounting plate with the screw terminals
The housing engages in the mounting plate and is secured with 2 screws on the
left side.
RDG100
RDG110
RDG140
RDG160
RDG100T
For operation, refer to section 5.2.
7.2 Dimensions
3181M101
Dimensions in mm
