Siemens RDG100, RDG100T, RDG110, RDG140, RDG160 Basic Documentation CE1P3181en
Building Technologies Summary 28 May 2009
• Advanced fan control function, i.e. fan kick, fan start, selectable fan operation
(enable, disable or depending on heating or cooling mode)
• Purge function together with 2-port valve in a 2-pipe changeover system
• Reminder to clean filters
• Floor heating temperature limit
• Reload factory settings for commissioning and control parameters
• 7-day time program: 8 programmable timers to switch over between Comfort
and Energy Saving mode (RDG100T)
• Infrared remote control (RDG100T)
2.2 Types and features
Features
Number of control outputs
Product
no.
Operating voltage
ON/OFF PWM 3-pos
DC
0..10 V
Time program
Backlit LCD
Infrared receiver
1)
ECM Fan
2)
RDG100
AC 230 V
3
3)
2
3)
2
3)
RDG100T
AC 230 V
3
3)
2
3)
2
3)
RDG110
AC 230 V
2
4)
RDG140
AC 24 V
2
RDG160
AC 24 V
2
1) Infrared remote control must be ordered as a separate item
2) ECM fan output DC 0…10 V
3) ON/OFF, PWM or 3-position (triac outputs)
4) Relay output (SPDT)
