Chapter 2
Installing the Device
RUGGEDCOM RS900G
Installation Guide
10 Connecting Low DC Power
1 3
2
4
Figure 6: Terminal Block Wiring - Single DC Power Supply Inputs
1. Positive Terminal 2. Negative Terminal 3. Surge Ground Terminal 4. Braided Ground Cable
1 3 1
2 2
4
Figure 7: Terminal Block Wiring - Dual DC Power Supply Inputs
1. Positive Terminal 2. Negative Terminal 3. Surge Ground Terminal 4. Braided Ground Cable
