Siemens RUGGEDCOM WIN5123 Installation Guide

Chapter 2
Installing the Subscriber Unit
RUGGEDCOM WIN5214
Installation Guide
6 General Procedure
IMPORTANT!
This product should be installed in a restricted access location where access can only be gained by
authorized personnel who have been informed of the restrictions and any precautions that must be
taken. Access must only be possible through the use of a tool, lock and key, or other means of security,
and controlled by the authority responsible for the location.
IMPORTANT!
Install equipment in accordance with the electrical code relevant to the country of installation, such as:
• the National Electrical Code (NEC), ANSI/NFPA 70
• the Canadian Electrical Code (CEC), Part 1, CSA C22.1
• the National Electrical Safety Code IEEE C2 (when applicable)
Unless marked or otherwise identified, the Standard for the Protection of Electronic Computer/Data
Processing Equipment, ANSI/NFPA 75, also applies.
IMPORTANT!
Outdoor exposed communication lines longer than 40 m (140 ft) must be considered as TNV-1 circuits.
The installer must make sure the power supply and network ports are designed for full compliance with
the standards for TNV-1 telecommunication networks.
CONTENTS
• Section2.1, “General Procedure”
• Section2.2, “Unpacking the Subscriber Unit”
• Section2.3, “Site Preparation and Precautions”
• Section2.4, “Installing the Subscriber Unit in Hazardous Locations”
• Section2.5, “Mounting the Subscriber Unit”
• Section2.6, “Grounding the Subscriber Unit”
• Section2.7, “Connecting Power and Data”
• Section2.8, “Weatherproofing the Subscriber Unit”
Section2.1
General Procedure
The general procedure for installing the subscriber unit is as follows:
IMPORTANT!
Before installing the subscriber unit in a Class I, Division 2 hazardous location, make sure to review the
conditions for safe use. For more information, refer to Section2.4, “Installing the Subscriber Unit in
Hazardous Locations”.
1. Review the relevant certification information for any regulatory requirements. For more information, refer to
Section5.1, “Approvals”.
2. Unpack and inspect the subscriber unit components. For more information, refer to Section2.2, “Unpacking
the Subscriber Unit”.

Siemens RUGGEDCOM WIN5123 Specifications

General

Brand	Siemens
Model	RUGGEDCOM WIN5123
Category	Wireless Router
Language	English
