RUGGEDCOM WIN5214
Installation Guide
Chapter 2
Installing the Subscriber Unit
Unpacking the Subscriber Unit 7
3. Mount the subscriber unit to a pole, wall or tower. For more information, refer to Section2.5, “Mounting the
Subscriber Unit”.
4. Assemble the PoE cable. For more information, refer to Section2.7.3, “Assembling the PoE Connector”.
5. Make sure the subscriber unit is grounded. For more information, refer to Section2.6, “Grounding the
Subscriber Unit”.
6. Connect the subscriber unit to a power source and the network. For more information, refer to Section2.7,
“Connecting Power and Data”.
7. Seal all cable connections. For more information, refer to Section2.8, “Weatherproofing the Subscriber Unit”.
8. Configure the subscriber unit. For more information, refer to Section3.1, “Configuring the Subscriber Unit”.
Section2.2
Unpacking the Subscriber Unit
The following items are included in the RUGGEDCOM WIN5214 package:
Item Quantity
RUGGEDCOM WIN5214 Subscriber Unit 1
RUGGEDCOM WIN1010 AC Power Injector 1
Radio Frequency (RF) antenna cables, 5 m (16.4 ft) long 2
Pole/wall/tower mounting kit 1
RJ45 PoE Connector Kit 1
When unpacking the subscriber unit, do the following:
1. Inspect the package for damage before opening it.
2. Visually inspect each item in the package for any physical damage.
3. Verify all items are included.
If any item is missing or damaged, contact Siemens for assistance.
Section2.3
Site Preparation and Precautions
Before installing the subscriber unit and or antenna(s), it is important to plan the the complete installation and
make sure the appropriate safe guards are in place.
Site Selection
Consider the following recommendations when selecting an appropriate site for the subscriber unit and
antenna(s):
• Mount the antenna(s) at the highest point possible. Reception will increase according to the height of the
antenna(s).
• Mount the antenna(s) in a place with as few obstructions as possible between the antenna(s) and the planned
service area.
