Chapter 2
Installing the Subscriber Unit
Installing the Subscriber Unit in Hazardous Locations 9
Section2.4
Installing the Subscriber Unit in Hazardous
Locations
The RUGGEDCOM WIN5214 is designed to comply with the safety standards for Class I, Division 2, Zone 2
hazardous locations where concentrations of flammable gases, vapors or liquids may be present, as opposed to
normal operating environments.
Special Conditions for Safe Use
Installation and use of the subscriber unit in a hazardous location must meet the following special conditions for
safe use:
• Substitution of components may impair suitability for Class I, Division 2
• Do not disconnect equipment unless power has been switched off or the area is known to be non-hazardous
• Use only Lambda DPP50-48 Power Supply in conjunction with the unit
NOTE
For further details of the subscriber unit's compliance with Class I, Division 2, Zone 2 standards, refer to
Section5.1, “Approvals”.
Sample Hazardous Location Label
The following is an example of the RUGGEDCOM WIN5214 hazardous location label:
P/N: WiN52XX-Y-ZZZ
CPE xxxx-xxxx MHz
S/N:
XXXXWWYYXX
WARNING - EXPLOSION HAZARD
DO NOT SEPARATE WHILE CIRCUIT IS LIVE
UNLESS AREA IS KNOWN TO BE SAFE
AVERTISSEMENT - RISQUE D'EXPLOSION
NE PAS DÉBRANCHER TANT QUE LE CIRCUIT EST SOUS TENSION,
À MOINS QU'IL NES S'AGISSE D'UN EMPLACEMENT NON DANGEREUX
I I 3 G n A I I C T 4 X
Rating: DC 48V, 1A
Class I Division 2 Groups A, B, C, D
T4
Figure2:Compliance Label (Example)
Section2.5
Mounting the Subscriber Unit
The RUGGEDCOM WIN5214 is designed for maximum mounting and display flexibility. It can be secured to a
bracket and then mounted to a pole, wall or tower.
NOTE
For detailed dimensions of the subscriber unit, refer to Section4.6, “Dimension Drawings”.
