Siemens RUGGEDCOM WIN5123 Installation Guide

Chapter 4
Technical Specifications
RUGGEDCOM WIN5214
Installation Guide
28 Operating Environment
Transmit Power Level
(Adjustable)
54dB
Size of Fast Fourier Transform
(FFT) Channels
1024/512FFT
Type of Modulation QPSK, 16-QAM, 64-QAM
Dynamic Range (Receiver) -20 to 100 dBm
Dynamic Range (Transmitter) -20 to 27 dBm
Section4.3
Operating Environment
The RUGGEDCOM WIN5214 is rated to operate under the following environmental conditions.
Ambient Operating
Temperature
a
-40 to 75 °C (-40 to 167 °F)
Ambient Storage Temperature -40 to 75 °C (-40 to 167 °F)
Ambient Relative Humidity
b
5% to 95%
Maximum Altitude 2000 m (6562 ft)
a
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure
b
Non-condensing
Section4.4
Mechanical Specifications
Weight 1.5 kg (3.3 lb)
Ingress Protection IP67
Enclosure Aluminum
Section4.5
IDU to ODU Cable Specifications
IDU to ODU Cable
Applications Outdoor installations, fixed or portable installations, digital distribution frames in transmission stations,
outdoor installations in harsh environments.
General Construction Custom made cable designed specially for wireless systems, meeting the requirements of Cat. 5e per
ANSI/TIA/EIA-568-B.2 and IEC 61156-5. The cable contains 4 twisted pairs, cabled, foil-tape shielded and
jacketed with two special black UV resistant, flame retardant PVC compounds for direct outdoor use in
harsh electrical environments. The diameter of the inner core complies with RJ45 connecting hardware
allowing direct connection to equipment without patch cords.
