Cabinet feedthrough
Component Description Article number
IE M12 PANEL
FEEDTHROUGH
Cabinet feedthrough for conversion from M12 connector
technology (D-coded, IP65) to RJ-45 connector technolo‐
gy (IP20)
pack of 5
6GK1901-0DM20-2
AA5
IE M12 PANEL
FEEDTHROUGH
PRO
Cabinet feedthrough for conversion from M12 connector
technology (D-coded, IP65) to M12 connector technology
(D-coded, IP65)
pack of 5
6GK1901-0DM30-2
AA5
IE M12 PANEL
FEEDTHROUGH
4X2
Cabinet feedthrough for conversion from M12 connector
technology (X-coded, IP65/67) to RJ-45 connector tech‐
nology (X-coded, IP20)
pack of 5
6GK1901-0DM40-2
AA5
N-Connect/N-Con‐
nect female/female
Panel Feedthrough
Panel feedthrough for wall thicknesses up to a maximum
of 4.5 mm, two N-Connect female connectors.
6GK5798-2PP00-2
AA6
N-Connect/SMA-
Connect female/fe‐
male Panel Feed‐
through
Panel feedthrough for wall thicknesses up to a maximum
of 5.5 mm, two N-Connect/SMA female connectors.
6GK5798-0PT00-2
AA6
Lightning protection
Component Description Article number
LP798‑1N Lighting protector with N/N female/female connector with gas dis‐
charge technology
6GK5798-2LP00-2
AA6
LP798‑2N Lighting protector with N/N female/female connector with quarter
wave technology
6GK5798-2LP10-2
AA6
Terminating resistor
Component Description Article number
TI795-1R Electrical connection
RSMA-Connect, male
6GK5795-1TR10-0
AA6
Description of the device
3.4 Accessories
SCALANCE W760/W720
Operating Instructions, 09/2017, C79000-G8976-C322-08 15
