5.2 Power supply
The power is supplied to the SCALANCE W760/W720 via the three-pin socket. Here the device
is also grounded.
s
L1
P1R1 F
SCALANCE
W700
R1A1
L+ M
Socket
The three-pin socket has the following pin assignment:
Pin Assignment
L+ +24 VDC
M Ground
Grounding
Connection
5.2 Power supply
SCALANCE W760/W720
Operating Instructions, 09/2017, C79000-G8976-C322-08 33
