Description of the device
3
3.1 Description of the device
W76x / W72x
s
L1 P1R1 F
SCALANCE
W700
R1A1
① LEDs
② Antenna connector
③ RESET button
④ Ethernet connector
⑤ Connector for power supply and grounding
SCALANCE W760/W720
Operating Instructions, 09/2017, C79000-G8976-C322-08 11
