Installation and removal
5.4 Installation on a DIN rail
SCALANCE W778-1 / W738-1
46 Operating Instructions, 03/2022, C79000-G8976-C450-07
2. Screw (tightening torque 0.7 Nm) the bracket holder to the side of the device.
3. Place the device on the upper edge of the DIN rail
.
4. Press the device against the DIN rail until he DIN rail slider catch locks in place.
