Installation and removal
5.4 Installation on a DIN rail
SCALANCE W778-1 / W738-1
Operating Instructions, 03/2022, C79000-G8976-C450-07
47
5. Connect the power supply, refer to the section "Power supply (Page 54)".
6. Fit the antennas, refer to the section "Antennas (Page 57)".
Uninstalling
1. Turn off the power to the device.
2. Disconnect all connected cables.
3. Pull the DIN rail slider down with a screwdriver
.
4. Tilt the device forward
and remove the device from the DIN rail.
5. Loosen the screws completely.
