Basic Information on Wireless LAN
Communication
1
1.1 Network Structure
Standalone Configuration with the SCALANCE W78x
This configuration does not require a server and the SCALANCE W78x does not
have a connection to a wired Ethernet. Within its transmission range, the
SCALANCE W78x forwards data from one WLAN node to another.
The wireless network has a unique name. All the devices exchanging data within
this network must be configured with this name.
Figure 1-1 Standalone Configuration of a SCALANCE W78x. The gray area indicates
the wireless transmission range of the SCALANCE W78x.
Operating Instructions SCALANCE W78x
13
C79000-G8976-C184-07
