Connecting
6.4 Power supply
SCALANCE X-300
Operating Instructions, 02/2012, A5E01113043-12
135
CAUTION
Securing cables with dangerous voltage
Make sure that the connector cannot be released accidentally by pulling on the connecting
cable. Lay the cables in cable ducts or cable channels and secure the cables, where
necessary, with cable ties.
CAUTION
Securing cables with dangerous voltage
Make sure that the connector cannot be released accidentally by pulling on the connecting
cable. Lay the cables in cable ducts or cable channels and secure the cables, where
necessary, with cable ties.
6.4.2.1 Fitting the connector for 100 to 240 V AC
WARNING
Use only two-wire cables
The connector can only fitted correctly to two-wire cables. If used with cables with more
than two cores, correct functioning of the connector casing cannot be guaranteed.
In this case, human life may be endangered by the line voltage because the two halves of
the casing can separate!
