11.1 Dimension drawing
Note
The IE Switches X-300 a
re available in small, medium and large variants.
The dimension drawings are shown below.
Small design
Figure 11-1 Small design dimension drawing (example used here SCALANCE X306-1LD FE)
SCALANCE X-300
Operating Instructions, 02/2012, A5E01113043-12
279
