Description of the device
4.2 Product groups
SCALANCE X-300
48 Operating Instructions, 02/2012, A5E01113043-12
4.2.1.2 SCALANCE X306-1LD FE product characteristics
Possible attachments
The SCALANCE X306-1LD FE has 6 RJ-45 jacks and 1 FO port (for single mode fiber) for
attachment of end devices or further network segments.
Figure 4-2 SCALANCE X306-1LD FE
Column 1 2
P4 P1 *
2
)
P5
P2 P6
Port number
P3 P7
Connection type
electrical
No marking → Fast Ethernet port
*
1
) marking → gigabit Ethernet port
Connection type
optical
*
2
) marking → Fast Ethernet port
*
3
) marking → gigabit port
