Technical specifications
8.6 XR-300M EEC technical specifications
SCALANCE X-300
Operating Instructions, 02/2012, A5E01113043-12
185
Media module
1)
Storage/transport
temperature
Operating temperature
2)
Max. relative
humidity in
operation at 25 °C
Max. ambient
temperature at operating
altitude
MM992-2SFP and the
following SFP
transceivers:
SFP991-1.
SFP991-1LD,
SFP992-1.
SFP992-1LD
-40 °C to +70 °C Horizontal installation:
-40 °C to +70 °C
SFP transceivers of
this group may only be
used in conjunction
with media modules
MM992-2CUC and
MM992-2CU. When
using other modules:
-40 °C to +60 °C
Vertical installation:
-40 °C to +50 °C
< 95 % (no
condensation)
Horizontal installation:
max. 65 °C as of 2 000 m
max. 60 °C as of 3 000 m
When using other
modules:
max. 55 °C as of 2 000 m
max. 50 °C as of 3 000 m
Vertical installation:
max. 45 °C as of 2 000 m
max. 40 °C as of 3 000 m
MM992-2SFP and the
following SFP
transceivers:
SFP991-1LH+,
SFP992-1LH,
SFP992-1LH+,
SFP992-1ELH
SFP991-1ELH200
-40 °C to +70 °C Horizontal installation:
Max. 2 modules in
slots 11 and 12:
-40 °C to +60 °C
With more than 2
modules or other slot
assignment:
-40 °C to +50 °C
Vertical installation:
-40 °C to +50 °C
< 95 % (no
condensation)
Horizontal installation:
max. 45 °C as of 2 000 m
max. 40 °C as of 3 000 m
Vertical installation:
max. 45 °C as of 2 000 m
max. 40 °C as of 3 000 m
1)
Only hardware product version 02 of the media modules is permitted.
The hardware product version is shown on the product. You can also read out this information from the device with the
WBM or the CLI.
2)
The permitted operating temperature depends on how the mounting device was installed. The installation is horizontal if
the device labeling is from left to right. With a vertical installation, the device labeling is rotated through 90°.
