Technical specifications
8.10 SFP technical specifications
SCALANCE X-300
214 Operating Instructions, 02/2012, A5E01113043-12
Table 8- 129 Installation options (modular)
Modular installation options: Device:
Transceiver
(Variant)
Media module installation in slot SFP installation in SFP media module
SFP991-1 (1 x 100 Mbps, LC port optical,
multimode glass, up to max. 3 km)
- ●
SFP991-1LD (1 x 100 Mbps, LC port optical, single
mode glass, up to max. 26 km)
- ●
SFP991-1LH+ (1 x 100 Mbps, LC port optical, single
mode glass, up to max. 70km)
- ●
SFP992-1 (1 x 1000 Mbps, LC port optical,
multimode glass, up to max. 750m)
- ●
SFP992-1LD (1 x 1000 Mbps, LC port optical,
single mode glass, up to max. 10km)
- ●
SFP992-1LH (1 x 1000 Mbps, LC port optical,
single mode glass, up to max. 40km)
- ●
SFP992-LH+ (1 x 1000 Mbps, LC port optical,
single mode glass, up to max. 70km)
- ●
SFP992-1ELH (1 x 1000 Mbps, LC port optical,
single mode glass, up to max. 120km)
- ●
*) Note: When used in shipbuilding, installation on a 35 mm DIN rail is not permitted. In ships, the 35 mm DIN rail does not provide
adequate support.
