Installation
Figure 6: Low-voltage compartment
Item Description
A Opening for manual charging
B Operator compartment
C Manual close pushbutton
D Manual open pushbutton
E Low-voltage compartment
F CHARGED/DISCHARGED indicator
G OPEN/CLOSE indicator
H Operations counter
I Control disconnect device
