Siemens SED2-4/35B - Access to Connection Terminals: Frame Sizes D to F IP20

28/126
Siemens Building Technologies SED2 variable speed drives CM1U5192en
HVAC Products Electrical installation 01.2002
4.3.3 Access to connection terminals: Frame sizes D to F IP20
Refer to the relevant paragraph in Access to connection terminals: Frame size A.
3
1
2
5
6
4
5
1
9
2
J
1
3
Removing the operator
panel (BOP or AOP)
Opening the housing:
Frame sizes D and E
