Siemens SED2 Series User Manual

35/126
Siemens Building Technologies SED2 variable speed drives CM1U5192en
HVAC Products Electrical installation 01.2002
Input voltage range 200 V – 240 VAC, 3-phase
Output
rating
kW (hp)
Min. cross-
section of
supply cable
mm
2
(AWG)
Max. cross-
section of supply
cable
mm
2
(AWG)
Min. cross-
section of motor
cable
mm
2
(AWG)
Max. cross-
section of motor
cable
mm
2
(AWG)
11 (15) 16 (5) 35 (2) 16 (5) 35 (2)
15 (20) 16 (5) 35 (2) 16 (5) 35 (2)
18.5 (25)
25 (3) 35 (2) 25 (3) 35 (2)
22 (30) 35 (2) 35 (2) 35 (2) 35 (2)
30 (40) 50 (0) 150 (-5) 50 (0) 150 (-5)
37 (50)
70 (-2) 150 (-5) 70 (-2) 150 (-5)
45 (60) 70 (-2) 150 (-5) 95 (-3) 150 (-5)
Input voltage range 380 V – 480 VAC, 3-phase
Output
rating
kW (hp)
Min. cross-
section of
supply cable
mm
2
(AWG)
Max. cross-
section of supply
cable
mm
2
(AWG)
Min. cross-
section of motor
cable
mm
2
(AWG)
Max. cross-
section of motor
cable
mm
2
(AWG)
0.37 (0.5)
1 (17) 2.5 (13) 1 (17) 2.5 (13)
0.55 (0.75) 1 (17) 2.5 (13) 1 (17) 2.5 (13)
0.75 (1)
1 (17) 2.5 (13) 1 (17) 2.5 (13)
1.1 (1.5)
1 (17) 2.5 (13) 1 (17) 2.5 (13)
1.5 (2) 1 (17) 2.5 (13) 1 (17) 2.5 (13)
2.2 (3)
1(17)6(9)1(17)6(9)
3(4)
1(17)6(9)1(17)6(9)
4(5) 1(17)6(9)1(17)6(9)
5.5 (7.5)
2.5 (13) 10 (7) 2.5 (13) 10 (7)
7.5 (10)
4(11) 10(7) 4(11) 10(7)
11 (15) 6 (9) 10 (7) 6 (9) 10 (7)
15 (20)
10 (7) 35 (2) 10 (7) 35 (2)
18.5 (25)
10 (7) 35 (2) 10 (7) 35 (2)
22 (30) 16 (5) 35 (2) 16 (5) 35 (2)
30 (40)
25 (3) 35 (2) 25 (3) 35 (2)
37 (50)
25 (3) 35 (2) 35 (2) 35 (2)
45 (60) 35 (2) 150 (-5) 35 (2) 150 (-5)
55 (75)
70 (-2) 150 (-5) 70 (-2) 150 (-5)
75 (100)
70 (-2) 150 (-5) 95 (-3) 150 (-5)
90 (125)
70 (-2) 150 (-5) 95 (-3) 150 (-5)
Input voltage range 500 V – 600 VAC, 3-phase
Output
rating
kW (hp)
Min. cross-
section of
supply cable
mm
2
(AWG)
Max. cross-
section of supply
cable
mm
2
(AWG)
Min. cross-
section of motor
cable
mm
2
(AWG)
Max. cross-
section of motor
cable
mm
2
(AWG)
0.75 (1)
1 (17) 10 (7) 1 (17) 10 (7)
1.1 (1.5)
1 (17) 10 (7) 1 (17) 10 (7)
1.5 (2)
1 (17) 10 (7) 1 (17) 10 (7)
2.2 (3)
1 (17) 10 (7) 1 (17) 10 (7)
3(4)
1 (17) 10 (7) 1 (17) 10 (7)
