Startup Procedure and Checklist SED2 Variable Frequency Drives
Document Number 155-718
September 14, 2011
Page 8 Siemens Industry, Inc.
Quick Commissioning Procedure
P0010 Start Quick Commissioning
0 = Ready to Run
1 = Quick Commissioning
30 = Factory Setting
NOTE: P0010 must always be set back to 0
before operating the motor. However, if
P3900 = 1 is set after commissioning, this
is done automatically.
P0100 Operation for Europe/ N. America
0 = Power in kW; f default 50 Hz
1 = Power in hp; f default 60 Hz
2 = Power in kW; f default 60 Hz
NOTE: Use DIP switches to permanently
change settings 0 and 1.
* P0304 Rated Motor Voltage
10 - 2000V
Nominal motor voltage (V) from rating plate.
* P0305 Rated Motor Current
0.01 - 10000A
Nominal motor current (A) from rating plate.
* P0307 Rated Motor Power
0.01 - 2000 kW or hp
Nominal motor power (kW or hp) from rating
plate. If P0100 = 1, values will be in hp.
* P0310 Rated Motor Frequency
12 - 650 Hz
Nominal motor frequency (Hz) from rating plate.
* P0311 Rated Motor Speed
0 - 40000 1/min
Nominal motor speed (rpm) from rating plate.
P1120 Ramp-up Time
0 - 650s
Time taken for the motor to accelerate from
standstill up to the maximum motor frequency.
** P0700 Selection of Command Source
(on/off/reverse)
0 = Factory Setting
1 = Basic Operator Panel
2 = Terminal/Digital Inputs
6 = P1/N2 Communications
P1082 Maximum Motor Frequency
Maximum motor frequency (0 - 650 Hz)
at which the motor will run irrespective of
the frequency setpoint. This value is valid
for both clockwise and counterclockwise
rotation.
P1080 Minimum Motor Frequency
Minimum motor frequency (0 - 650 Hz)
at which the motor will run irrespective of
the frequency setpoint. This value is valid
for both clockwise and counterclockwise
rotation.
** P1000 Selection of Frequency Setpoint
(on/off/reverse)
0 = No Frequency Setpoint
1 = MOP Frequency Control
2 = Analog Setpoint
6 = P1/N2 Communications
P3900 End Quick Commissioning
0 = End commissioning without motor calculation
or factory reset.
1 = End commissioning with motor calculation and
factory reset (recommended without bypass).
2 = End commissioning with motor calculation and
with I/O reset.
3 = End commissioning with motor calculation but
without I/O reset (recommended with
bypass option).
P1121 Ramp-down Time
0 - 650s
Time taken for the motor to decelerate from
the maximum motor frequency down to standstill.
Motor related parameters.
Parameters that have more possible settings for use
in specific applications.
*
**
User Setting
User Setting
User Setting
User Setting
User Setting
User Setting
User Setting
User Setting
User Setting
User Setting
User Setting
User Setting
User Setting
User Setting
Recommended:
(Fan: 60-120s,
Pump: 10-20s)
(20-30% Max)
Recommended:
(Fan: 60-120s,
Pump: 10-20s)
