Siemens SED2

20
Appendix 1: - P1 Communications Set-up and Point Map
Parameter Set-up: The Table below lists the Parameters and the setting values required for proper
P1 FLN communication and control
Parameter number/name Value
P0003: User access level Set to 3 to allow access to required parameters.
P2040: CB telegram off time Set to 0 to tell the drive to start looking for communication via setting of
P2041.
P2041(index 0): CB parameter Set to “1 Set to "0" for FLN (P1) control (set to "1" for FLN (N2) control).
P0918: CB address
Set to “1-99” for addressing of the device.
P0700 (index 0)
Set to 6 tells the SED2 to look for a start command from P1 in the auto mode.
P1000 (index 0)
Set to 6 tells the SED2 to look for its speed source from P1 in the auto mode.
P1 Point Map
Point Number
(drive
parameter)
Point
Type
Descriptor Factory Default
(SI Units)
Engr. Units
(SI Units)
Slope
(SI Units)
Intercept
(SI Units)
On Text Off Text
01 LAO CTLR ADDRESS 99 – 1 0 – –
02 LAO APPLICATION 2722 – 1 0 – –
(03) LAI FREQ OUTPUT 0 HZ .04 -650 – –
(05) LAI SPEED 0 RPM 1 -16250 – –
(06) LAI CURRENT 0 A 0.5 0 – –
(07) LAI
TORQUE
0
NM
.02 -3250 – –
(08) LAI ACTUAL POWER 0 HP/KW .01 0 – –
(09) LAI TOTAL KWH 0 KWH 1 0 – –
(13) LAI DC BUS VOLT 0 V 1 0 – –
(14) LAI REFERENCE 0 HZ .04 -650 – –
(16) LAI RATED PWR 0 HP/KW .01 0 – –
(17) LAI
OUTPUT VOLTS
0
V
1 0 – –
20 LAO OVRD TIME 1 HRS 1 0 – –
(21) LDI FWD.REV FWD – 1 0 REV FWD
(22) LDO CMD FWD.REV FWD – 1 0 REV FWD
