Siemens SED2

21
Point Number
(drive
parameter)
Point
Type
Descriptor Factory Default
(SI Units)
Engr. Units
(SI Units)
Slope
(SI Units)
Intercept
(SI Units)
On Text Off Text
(23) LDI STOP.RUN STOP – 1 0 RUN STOP
(24) LDO CMD STP.STRT STOP – 1 0 START STOP
(25) LDI AT MAX FREQ NO – 1 0 MAX NO
(26) LDI CONTROL MODE SERIAL – 1 0 SERIAL LOCAL
(27) LDI ENABLED OFF – 1 0 ENABLED OFF
(28) LDI READY TO RUN OFF – 1 0 READY OFF
(29) LDO DAY.NIGHT DAY – 1 0 NIGHT DAY
30 LAO CURRENT LIM 1400 PCT .1 10 – –
31 LAO ACCEL TIME 1 500 SEC .02 0 – –
32 LAO DECEL TIME 1 500 SEC .02 0 – –
34 LDO SEL HND.AUTO AUTO – 1 0 AUTO HAND
(35) LDO RUN ENABLE ENABLE – 1 0 ENABLE OFF
40 LDO DIGITAL OUT 1 OFF – 1 0 ON OFF
41 LDO DIGITAL OUT 2 OFF – 1 0 ON OFF
(45) LAI ANALOG IN 1 0 PCT .1 -300 – –
(46) LAI ANALOG IN 2 0 PCT .1 -300 – –
(47) LAI ANALOG OUT 1 0 PCT .1 -100 – –
(48) LAI ANALOG OUT 2 0 PCT .1 -100 – –
(51) LAO FREQ REF 0 PCT 0.0061 0 – –
(52) LA1 FREQ ACTUAL 0 PCT 0.0122 -100 – –
53 LAO FREQ MAX 2450 HZ 0.2 1 – –
(55) LAO PID SETP REF 8602 PCT 0.0244 -200 – –
(56) LAI PID SETP OUT 0 PCT 0.0122 -100 – –
57 LAO PID UP LMT 12288 PCT 0.0244 -200 – –
58 LAO PID LO LMT 8192 PCT 0.0244 -200 – –
(59) LAI PID OUTPUT 0 PCT 0.0122 -100 – –
(60) LAI PI FEEDBACK 0 PCT 0.0122 -100 – –
