Siemens SIDOOR AT40 System Manual

Power supply
8.1 SIDOOR NT40
AT40, ATD400V, ATD400K, ATD4xxW, ATD400S, ATE250S, ATD400T
System Manual, 06/2016, A2B00096162-AN
265
8.1.4
Technical specifications
Order number
6FB1112-0AT20-3PS0
General technical data:
product brand name
SIDOOR
Product designation
Switched-mode power
supply
Design of the product
NT40
Electical data:
Supply voltage with AC
V
230
Supply voltage frequency
• with AC
Hz
47 ... 63
Relative symmetrical tolerance of the supply voltage
%
15
Input current at rated input voltage 230 V Rated value
A
0.7
Operating current of fuse protection at input when installing maxi-
mum
A 10
Consumed current
• for 2 s maximum
A
3.5
Apparent power consumption maximum
V·A
650
Active power supplied
• maximum
W
100
• restricted to 2 s
W
540
Efficiency at 100 W active power output at 230 V AC
%
90
Operating resource protection class
I
Overvoltage category
2
Output voltage for DC Rated value
V
36
Output voltage for DC Rated value Note
SELV
Relative symmetrical tolerance of the output voltage
%
3
Output current
• minimum rated value
A
0
• maximum rated value
A
2.5
Active power consumption maximum Rated value
W
100
Short-term overload current for maximum 2 s
A
15
Tripping characteristic class of fuse protection at input when in-
stalling
B
