Technical specifications
11.8 Technical specifications
Mobile Panels 2nd Generation
Operating Instructions, 09/2018, A5E33876626-AC
237
Internal switches of the connection box standard and connection box advanced
Industrial Ethernet switch of the
Industrial Ethernet switch of the
A detailed description of the internal SCALANCE switches of both connection boxes is
available in the following documents:
● Operating instructions "SCALANCE X-200"
(https://support.industry.siemens.com/cs/ww/en/view/102051962
)
● Configuration manual "SCALANCE X-200"
(https://support.industry.siemens.com/cs/ww/de/view/109476763
)
Insulation testing, protection class and degree of protection
Insulation testing
The insulation strength is demonstrated in the type test with the following test voltages in
accordance with IEC 61131-2:
Insulation tested with (type test)
e
707 V DC to other circuits / to ground
Ethernet connector 1500 V AC
Protection class III according to IEC 61131-2
Protection against foreign objects and water
The device meets the following degrees of protection to IEC 60529 under the following
requirements.
● Connection box compact: The connection box has been installed as described in this
document.
Front When mounted:
• IP65 according to IEC 60529
• Type 4X/Type 12 (indoor use only) to UL50
Applies if indicated on the nameplate
Rear IP20
Protection against contact with standard test probes. There is no
protection against the ingress of water, dust and noxious gas.
