Installing system components
3.6 Connecting the connection box
Mobile Panels 2nd Generation
58 Operating Instructions, 09/2018, A5E33876626-AC
Inserting the USB memory stick
The USB port is used to transfer data and save specific HMI device data.
USB port only enabled for USB flash drive
The USB port is only enabled for use with an industrial-grade USB flash drive for
commissioning and maintenance purposes.
Degrees of protection not guaranteed with USB flash drive
When a USB flash drive is connected to the USB port, the degrees of protection specified
for the Mobile Panel are not guaranteed.
Do not connect a USB device if dust or moisture is present at the location of use that can
enter the HMI device.
● An industrial-grade USB flash drive
1. Remove the cover from the USB port.
2. Insert the USB flash drive into the slot.
Storage media (Page 22)
Functions for service and commissioning (Page 144)
