Siemens SIMATIC HMI KTP700F Mobile User Manual

Technical specifications
11.13 Scope of functions with WinCC
Mobile Panels 2nd Generation
Operating Instructions, 09/2018, A5E33876626-AC
255
Screens
KTP400F Mobile
KTP700 Mobile / KTP700F Mobile
KTP900 Mobile / KTP900F Mobile
Number of screens
500
Number of fields per screen 50 400
Number of tags per screen
50
400
Number of complex objects per
screen
1)
5 20
1
Complex objects include: Bars, sliders, symbol library, clock, and all objects from the Controls
area.
Recipes
KTP400F Mobile
KTP700 Mobile / KTP700F Mobile
KTP900 Mobile / KTP900F Mobile
Number of recipes
300
Number of elements per recipe
1)
1000
User data length in bytes per data
record
256 KB
Number of data records per recipe
500
Reserved memory for data records
in the internal Flash
2 MB
1
Each array element used in arrays represents a recipe element
Logs
KTP400F Mobile
KTP700 Mobile / KTP700F Mobile
KTP900 Mobile / KTP900F Mobile
Number of logs
50
Number of entries per log (including
all log segments)
1
20000
Number of sequential logs
400
Cyclic trigger for tag logging
1 s
Number of tags that can be logged
per log
2048
1
The number of entries for all segmented circular logs is valid for the "segmented circular log"
logging method. The product of the number of sequential logs and the number of data records per
sequential log may not exceed the system limit

Siemens SIMATIC HMI KTP700F Mobile Specifications

General

Brand	Siemens
Model	SIMATIC HMI KTP700F Mobile
Category	Touch Panel
Language	English
