Testing mechanical ambient conditions
The table below provides information on the type and scope of tests for mechanical ambient
conditions.
Tested for Test standard Comments
Vibration Vibration test according to
DIN EN 60068, part 2–6 (si‐
nusoidal)
Type of vibration:
Frequency cycles at a rate of change of 1 octave/minute.
5 Hz ≤ f ≤ 8.4 Hz, constant amplitude 3.5 mm
8.4 Hz ≤ f ≤ 200 Hz, constant acceleration 1 g
Vibration duration:
10 frequency cycles per axis in each of the three mutually vertical axes
Shock Shock test according to DIN
EN 60068, part 2 –27
Type of shock: Half-wave
Severity of shock:
Peak value 15 g, duration 11 ms
Direction of shock:
3 shocks in ± direction of axis in each of the three axes vertical to each
other
Climatic ambient conditions
The following table shows the climatic ambient conditions for operation of the device.
Ambient conditions Permissible range Comments
Temperature:
Vertical mounting
Mounting at an angle
From 0 to 45° C (horizontal)
From 0 to 40° C (horizontal)
Slope angle max. 35°
Relative humidity 10% to 90%, without condensation
Atmospheric pressure 1080 to 795 hPa Corresponds to an elevation of -1000 m to
2000 m
Pollutant concentration SO
2
: < 0.5 vpm;
Relative humidity < 60%, no condensation
Test: 10 cm
3
/m
3
; 21 days
H
2
S: < 0.1 vpm;
Relative humidity < 60%, no condensation
Test: 1 cm
3
/m
3
; 21 days
Technical specifications
7.1 Monitor
ERGOline Stage 3
Manual, 02/2015, 6FC5397-4FP40-0BA0 45
