Proceed in the same way to install the second rotary switch.
NOTICE
Damage to the components through incorrect installation of the rotary switches
● It is essential that the specified tightening torques are complied with.
● Make sure that the connection cable is cleanly folded as in the figure and lay it so that it
does not come into contact with any chafing edges.
Spare parts
8.2 Replacement
ERGOline Stage 3
Manual, 02/2015, 6FC5397-4FP40-0BA0 53
