SIMATIC IFP2200/2400 ITC2200/2400 frameless
18 A5E48015893-AC, 03/2021
Features
• Reinforced front in a frameless design
• Multi-touch technology; detection of up to 5 fingers simultaneously
• Scratch-proof, chemical-resistant and anti-glare glass front
• Intelligent operation fault recognition, e.g. palm, drops, dirt on the touch screen.
• Operation possible with thin working gloves
• LCD display, resolution 1920 x 1080 pixels
• 16 million colors
• 24 V DC power supply
Interfaces
IFP Extended versions
Connection for functional ground
X71 Ext link interface to the Transceiver Unit
X80 connector for 24 V DC power supply
X70 DisplayPort interface
ITC built-in units
Functional grounding connection
X1 P1 PROFINET (LAN), 10/100/1000 MBit
X80 power supply connector
X1 P2 LAN, 10/100/1000 MBit
"Factory settings" button
Safety instructions and further information
The general safety instructions in the underlying operating instructions apply, see section "Validity (Page 17)".
Intended use
Device protection is impaired
If the device is not used as intended, the degrees of protection assured for the device cannot be guaranteed and the
protection objectives cannot be fulfilled.
• Use the device as described in the documentation.
• Observe all notes and requirements.
