Mechanical ambient conditions
The mechanical ambient conditions for the device and the Transceiver Unit are specified in the table below in terms of
sinusoidal vibration.
Device type
Frequency range f in Hz
Comment
Vibration according to IEC 60068-2-6
5 Hz ≤ f ≤ 8.4 Hz (3.5 mm)
8.4 Hz ≤ f ≤ 200 Hz (9.8 m/s
2
)
Mechanical class 3
see table below
Shock pulses within the specified range can be transferred to the display but do not impact the functionality of the device.
The table below provides information on the type and scope of tests for mechanical ambient conditions.
Tested
for
Test standard
Comments
Vibration
s
Vibration test in accordance with IEC 60068, Part 2-6 (sine)
Vibration duration: Ten frequency cycles per axis in each of
the three mutually vertical axes
Type of vibration: Frequency cycles at a rate of change of 1
octave/minute.
Mechanical class 3:
5 Hz ≤ f ≤ 8.4 Hz, constant amplitude 3.5 mm
8.4 Hz ≤ f ≤ 200 Hz, constant acceleration 9.8 m/s
2
Shock
Shock test in accordance with IEC 60068, Part 2-27
Type of shock: Half-sine
Severity of shock: Peak value 15 g, duration 11 ms
Direction of shock: 3 shocks in ± direction of axis in
each of the three axes vertical to each other
Reducing vibration and shock
If the device is subjected to heavy shocks or vibrations, you must take appropriate measures to reduce acceleration or
amplitude during installation.
Climatic ambient conditions
The following table shows the climatic ambient conditions for operation of the device.
Ambient conditions
Permitted range
Comments
Temperature, vertical mounting:
0 ... 45 °C (landscape format)
0 ... 40 °C (portrait format)
Temperature, inclined mounting
1
0 ... 40 °C (landscape format)
0 ... 35 °C (portrait format)
Inclination: Maximum 35°
Transceiver Unit temperature
0 ... 50 °C
vertical, interfaces facing downward
Relative humidity
10% to 90%, without condensation
Atmospheric pressure
1140 to 795 hPa
Corresponds to an elevation
of -1000 to 2000 m
Pollutant concentration
SO
2
: < 0.5 ppm;
relative humidity < 60%, no condensation at
the rear of the device
Test: 10 cm
3
/m
3
; 21 days
H
2
S: < 0.1 ppm;
Relative humidity < 60%, no condensation at
the rear of the device
Test: 1 cm
3
/m
3
; 21 days
1
see section Permitted mounting positions (Page 19)
Note
Internal temperature of the enclosure
When the device is mounted, the internal temperature of the enclosure must not exceed 55
°C.
System components
All other
system components connected to the device, such as the power supply, must also be suited to the respective
operating conditions.
