Configuration without S7-PCT
You can activate the following parameters in STEP7 or the GSD file during port configuration:
•
Port Qualifier Information (PQI):
provides information on the status, such as process data of the IO-Link port; is transmitted
with the input data of the IO-Link device.
•
Operating mode
–
IO-Link Autostart:
The IO-Link master accepts each connected IO-Link device and starts it automatically.
–
IO-Link Manual:
The IO-Link master only accepts IO-Link devices that match the Vendor ID and Device ID
set below.
The connected IO-Link device is not started automatically.
–
DI:
The port is operating as a standard digital input.
–
DQ:
The port is operating as a standard digital output.
–
Disabled:
The port is disabled.
•
Input Data Length:
Process data length of the input data
•
Output Data Length:
Process data length of the output data
•
Vendor ID
ID number of the device manufacturer. You can find the Vendor ID on the Internet
(https://support.industry.siemens.com/cs/ww/en/view/109748852).
•
Device ID
ID number of the device. You can find the Device ID on the Internet
(https://support.industry.siemens.com/cs/ww/en/view/109748852).
•
Inspection level for data backup:
–
Identical type (V1.0) without Backup&Restore
–
Type-compatible (V1.1) without Backup&Restore
–
Type-compatible (V1.1) with Backup&Restore
–
Type-compatible (V1.1) with Restore
