Siemens SIMATIC IO-Link system - Page 25

Configuration without S7-PCTRequirement Configuration with S7-PCT
IO-Link Autostart IO-Link Manual
Adjustable IO-Link device para
meters
Yes No No
Display of the IO-Link process
data structure
Yes No No
Monitoring of IO-Link process
data
Yes No No
Display of IO-Link device dia
gnostics messages
Yes No No
Configuration options of the SIMATIC IO-Link masters
The following table provides an overview of the configuration options supported by the
individual IO-Link masters:
Configuration... Device designation Article number As of FW
version
...with S7-PCT ...without S7-PCT
ET 200MP
Communications module IO-Link Master
CM 8xIO-Link
6ES7547-1JF00-0A
B0
V1.0 x x
ET 200SP
V1.0.0 x -Communications module IO-Link Master
CM 4xIO-Link
6ES7137-6BD00-0
BA0
V2.2.0 x x
ET 200AL
V1.0.0 x -Communications module CM 4xIO-Link
4xM12
6ES7147-5JD00-0B
A0
V1.1.0 x x
ET 200eco PN
IO-Link master
4IO‑L+8DI+4DODC24V/1,3A8×M12
6ES7148-6JA00-0A
B0
V6.1.0 x -
IO-Link master 4IO‑L4×M12 6ES7148-6JD00-0
AB0
V1.0.0 x x
IO-Link master 8x IO-Link + DIQ 8x24VDC
M12-L 8xM12
6ES7148-6JJ00-0B
B0
V1.0.0 x x
IO-Link master 4x IO-Link + DIQ
12x24VDC M12-L 8xM12
6ES7148-6JE00-0B
B0
V1.0.0 x x
ET 200pro
Electronic module EM 4 IO-LINK HF 6ES7147-4JD00-0
AB0
V1.0.0 x -
ET 200S
25
Integration into the automation system
3.1 Configuration of the IO-Link system
IO-Link system
Function Manual, 07/2022, A5E31637677-AC
