Performance data and behavior in operation
5.3 Characteristic data of the DP interface / DP slave
CP 342-5 / CP 342-5 FO
26 Manual, 10/2011, C79000-G8976-C146-09
Characteristic Explanation / values
CP 342-5 (6GK7 342-5DA03-0XE0) SI0180D6.GSD
CP 342-5 FO(6GK7 342-5DF00-0XE0) SIEM80D7.GSD
You will find the GSD files on the Internet under the following entry ID:
113652 (http://support.automation.siemens.
com/WW/view/en/113652)
DP input area 240 bytes max.
Size of the DP data
areas
DP output area 240 bytes max.
Min. slave interval 0.6 ms
CP 342-5 (6GK7 342-5DA03-0XE0) Is supported SYNC / FREEZE
CP 342-5 FO(6GK7 342-5DF00-0XE0) The following is not supported
User parameter assignment data 3 bytes; value: 40 00 00 (fixed)
User diagnostics data 0 bytes
NOTICE
Fail-safe
Fail-safe mode is possible only if you use the GSD files listed in the table above.
Execution times of the program blocks for PROFIBUS DP
The following table will help you to calculate the CPU cycle times (OB1) in DP slave mode.
The table contains the execution time of the FCs (FC DP_SEND, FC DP_RECV) required for
DP processing on the S7-300 / C7-300 CPU.
Component Explanation / values
Execution time on the CPU
314C-2DP (6ES7 314-6CF00-
0AB0)
Per DP_SEND block call:
<3.0 ms at 8 bytes
<5.0 ms at 240 bytes
Per DP_RECV block call:
<3.3 ms at 8 bytes
<5.8 ms at 240 bytes
Execution time on the CPU 317-
2PN/DP (6ES7 317-2EJ10-
0AB0)
Per DP_SEND block call:
<1.5 ms at 8 bytes
<2.3 ms at 240 bytes
Per DP_RECV block call:
<1.7 ms at 8 bytes
<2.8 ms at 240 bytes
