Installing the Device
2.6.1Connecting High AC/DC Power
2. Connect the positive wire from the power source to the positive/live (+/L)
terminal on the terminal block.
4
1 2 3
1
Positive/Live (+/L) Terminal
2
Negative/Neutral (-/N) Terminal
3
Surge Ground Terminal
4
Braided Ground Cable
Figure2.6 Terminal Block Wiring
14
RUGGEDCOM RS900
Installation Manual, 04/2022, C79000-G8976-1024-14
