Technical Specifications
5.6Operating Environment
5.6 Operating Environment
The RUGGEDCOM RS900 is rated to operate under the following environmental
conditions.
Ambient Operating
Temperature
a
-40 to 85 °C (-40 to 185 °F)
Ambient Storage Temperature -40 to 85 °C (-40 to 185 °F)
Ambient Relative Humidity
b
5% to 95%
Maximum Altitude 2000 m (6562 ft)
a
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure.
b
Non-condensing.
5.7 Mechanical Specifications
Weight 1.2 kg (2.7 lbs)
Ingress Protection IP30
Enclosure 20 AWG Galvanized Steel
5.8 Dimension Drawings
Note
All dimensions are in millimeters, unless otherwise stated.
28
RUGGEDCOM RS900
Installation Manual, 04/2022, C79000-G8976-1024-14
