Technical Specifications
5.5Fiber Optic Ethernet Port Specifications
Wiring Standard
c
TIA/EIA T568A/B
Maximum Distance
d
100 m (328 ft)
Isolation
e
2.5 kV
a
Auto-negotiating.
b
Shielded or unshielded.
c
Auto-crossover and auto-polarity.
d
Typical distance. Dependent on the number of connectors and splices.
e
RMS 1 minute.
5.5 Fiber Optic Ethernet Port Specifications
The following details the specifications for fiber Ethernet ports that can be ordered
with the RUGGEDCOM RS900.
Note
• All optical power numbers are listed as dBm averages. To convert from average
to peak, add 3 dBm. To convert from peak to average, subtract 3 dBm.
• Maximum segment length is greatly dependent on factors such as fiber quality,
and the number of patches and splices. Consult a Siemens sales associate when
determining maximum segment distances.
Tx (dBm)
Mode
Connector
Type
Tx λ
(nm)
a
Cable
Type (μm)
Minimum Maximum
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(km)
a
Power
Budget
(dB)
50/125 -22.5 -14 -33.5 -14 2 11
MM MTRJ 1300
62.5/125 -19 -14 -33.5 -14 2 14.5
50/125 -22.5 -14 -33.9 -14 2 11.4
MM SC 1300
62.5/125 -19 -14 -33.9 -14 2 14.9
50/125 -22.5 -14 -33.9 -14 2 11.4
MM ST 1300
62.5/125 -19 -14 -33.9 -14 2 14.9
MM LC 1310 62.5/125 -19 -14 -32 -14 2 13
SM ST 1310 9/125 -15 -7 -34 -3 20 19
SM LC 1300 9/125 -15 -8 -38 -3 20 23
SM LC 1310 9/125 -5 0 -35 -3 50 30
SM LC 1310 9/125 0 5 -37 0 90 37
SM SC 1300 9/125 -15 -8 -31 -7 20 16
SM SC 1310 9/125 -5 0 -34 -3 50 29
SM SC 1310 9/125 5 0 -37 0 90 42
a
Typical.
RUGGEDCOM RS900
Installation Manual, 04/2022, C79000-G8976-1024-14
27
