Installing the Device
2.4.2Mounting the Device to a Panel
Removing the Device
To remove the device from a DIN rail, do the following:
1. Insert a flathead screwdriver into the slot of the sliding release and move it
down.
1
2
1
2
1
3
1
DIN Rail
2
DIN Rail Adapter
Figure2.2 Removing the Device from a DIN Rail
2. Swing the bottom of the device away from the DIN rail.
3. Lift the device off the DIN rail.
2.4.2 Mounting the Device to a Panel
For panel installations, the RUGGEDCOM RS900G can be equipped with panel
adapters that allow the device to be attached to a panel using screws.
RUGGEDCOM RS900G
Installation Manual, 01/2021, C79000-G8976-1025-08
9
