Technical Specifications
5.4Fiber Optic Ethernet Port Specifications
Standard 10 Mbps
Ports
100 Mbps
Ports
1000 Mbps Ports Notes
IEEE 802.3 • 10Base-T
IEEE 802.3ad • • • Link aggregation
IEEE 802.3ae • 10GBase
IEEE 802.3u • 100Base-TX/100Base-FX
IEEE
1588-2008
• • • Precision Time Control
(PTP) Version 2
IEC
62439-2:2016
• • • Media Redundancy
Protocol (MRP)
IEC
62439-3:2016
• • • High-Availability Seamless
Redundancy (HSR), Parallel
Redundancy Protocol (PRP)
5.4 Fiber Optic Ethernet Port Specifications
The following details the specifications for fiber Ethernet ports that can be ordered
with the RUGGEDCOM RSG907R.
Note
• All optical power numbers are listed as dBm averages. To convert from average
to peak, add 3 dBm. To convert from peak to average, subtract 3 dBm.
• Maximum segment length is greatly dependent on factors such as fiber quality,
and the number of patches and splices. Consult a Siemens sales associate when
determining maximum segment distances.
Wavelength
(nm)
a
Transmit
Power (dBm)
Data
Rate
(Mbps)
Mode Connector Cable
(μm)
Transmit Receive Min Max
Receiver
Sensitivity
(dBm)
Receiver
Saturation
(dBm)
Distance
(km)
a
Power
Budget
100 MM LC 50/125 1308 1308 -22.5 -14 -31 -14 2 11
100 MM LC 62.5/125 1308 1308 -20 -14 -31 -14 2 11
a
Typical.
5.5 Operating Environment
The RUGGEDCOM RSG907R is rated to operate under the following environmental
conditions.
Ambient Operating
Temperature
ab
-40 to 85 °C (-40 to 185 °F)
Ambient Storage Temperature -40 to 85 °C (-40 to 185 °F)
Ambient Relative Humidity
c
5% to 95%
Maximum Altitude 2000 m (6562 ft)
a
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure.
RUGGEDCOM RSG907R
Installation Manual, 02/2021, C79000-G8976-1387-12
33
