Requirements for use
3.2 System environment
CP 443-1 (EX30)
Manual, 03/2019, C79000-G8976-C255-05
29
CPU
Order number of the
CPU: 6ES7...
as of firmware
version
a = multiprocessor mode
b = number of operable CPs
c = CPU resources for SEND/RECEIVE jobs
1
)
d = LOCK/UNLOCK
e = PROFINET IO
4)
a
b
c
d
e
CPU 416-2 ..416-2XN05-0AB0 V5.1
as of V5.2
+
2)
+
2)
14
14
64
64
+
+
-
+
CPU 416-3
..416-3XL04-0AB0
V4.1
+
2)
14
64
+
-
CPU 416-3 ..416-3XR05-0AB0 V5.1
as of V5.2
+
2)
+
2)
14
14
64
16
+
+
-
+
CPU 416-3
PN/DP
..416-3ER05-0AB0 V5.1
as of V5.2
+
2)
+
2)
14
14
64
64
+
+
-
+
CPU 416F-3
PN/DP
..416-3FR05-0AB0 V5.1
as of V5.2
+
2)
+
2)
14
14
64
64
+
+
-
+
CPU 416F-3
PN/DP
..416-3ES06-0AB0 as of V6.0.2 +
2)
14 64 + +
CPU 416F-3
PN/DP
..416-3FS06-0AB0 as of V6.0.2 +
2)
14 64 + +
CPU 417-4
..417-4XL04-0AB0
V4.1
+
2)
14
64
+
-
CPU 417-4 ..417-4XT05-0AB0 V5.1
As of V5.2
+
2)
+
2)
14
14
64
64
+
+
-
+
CPU 412-3H
3)
..412-3HJ14-0AB0
V4.5
+
2)
14
64
+
-
CPU 414H
3)
..414-4HM14-0AB0
V4.5
+
2)
14
64
+
-
CPU 417H
3)
..417-4HR14-0AB0
V4.5
+
2)
14
64
+
-
CPU 417-4H
3)
..417-4HT14-0AB0
V4.5
+
2)
14
64
+
-
CPU 412-5H
3)
..412-5HK06-0AB0 V6.0 +
2)
14 64 + -
CPU 414-5H
3)
..414-5HM06-0AB0
V6.0
+
2)
14
64
+
-
CPU 416-5H
3)
..416-5HS06-0AB0
V6.0
+
2)
14
64
+
-
CPU 417-5H
3)
..417-5HT06-0AB0
V6.0
+
2)
14
64
+
-
Legend:
+ => The characteristic is supported / the listed mode is possible
- => The characteristic is not supported / the listed mode is not possible
1) Note:
The calculation of the maximum number of SEND/RECEIVE calls that can be used simultaneously per CP is described
in the section "Characteristic data".
2) Note:
When operating the CP as a PROFINET IO controller, the multiprocessor mode is not supported, only the process im-
age of the assigned CPU can be distributed via the CP (note: this has no influence on communications protocols operat-
ing at the same time in multiprocessor mode).
3) Note: When operating with H
CPUs with a firmware version lower than V6.0, the SSEND / SRECV mode on the
SEND/RECV interface is not supported.
4) Note: The PROFINET IO mode Shared Device requires a CPU as of V5.3.
