Configuring with Web Based Management
4.3 "Information" menu
SCALANCE SC-600 Web Based Management (WBM)
92 Configuration Manual, 10/2021, C79000-G8976-C475-03
Description of the displayed values
The table contains the following columns:
• System Name
System name of the connected device.
• Device ID
Device ID of the connected device. The device ID corresponds to the device name
assigned via SINEC PNI (STEP 7). If no device name is assigned, the MAC address of
the device is displayed.
• Local Interface
Port at which the device received the information
• Hold Time
An entry remains stored on the device for the time specified here. If the device does
not receive any new information from the connected device during this time, the entry
is deleted.
• Capability
Shows the properties of the connected device:
– Router
– Bridge
– Telephone
– DOCSIS Cable Device
– WLAN Access Point
– Repeater
– Station
– Other
• Port ID
Port of the device with which the device is connected.
