Siemens SIMATIC NET SCALANCE W788-x User Manual

Description of the device
4.4 Accessories
SCALANCE W788-x / W748-1
24 Operating Instructions, 03/2022, A5E03678333-17
Cables Industrial Ethernet
Component
Description
Article number
IE FC TP cable
4 x 2
Industrial Ethernet FastConnect TP standard cable
GP 4 x 2, TP installation cable CAT6A for
connection to IE FC RJ45 Plug 4 x 2, 24 AWG
Sold by the meter
6XV1878-2A
* Available in different lengths
4.4.4 Power supply
Energy cable
Component
Description
Article number
Energy cable 2 x
0.75
Energy cable for connection of signaling contact
and power supply 24 VDC, stranded wire 2 x 0.75
mm
2
, trailing type, not assembled
Sold by the meter
6XV1812-8A
Robust Energy
Cable 4 x 0.75
Energy cable for connection of power supply 24
VDC, 4-wire stranded 4 x 0.75 mm
2
, robust,
flexible, not assembled
Sold by the meter
6XV1801-2A
M12 PLUG-IN
CABLE
Flexible plug-in power cable to connect the power
supply 24 VDC, 4-wire, preassembled with a 4-pin
M12 plug and an M12 socket (A-coded)
6XV1801-5D*
* Available in different lengths
Socket
Component
Description
Article number
IE POWER M12
CABLE
CONNECTOR
PRO
Socket for the 24 VDC power supply. 4-pin, A-
coded
pack of 3
6GK1907-0DC10-6AA3
4.4.5 Flexible connecting cables, antennas and accessories
You will find an overview of the IWLAN products and their accessories in the Order
overview (https://support.industry.siemens.com/cs/ww/en/view/109766333).
