PROFINET variants
● Industrial Ethernet protocol: PROFINET
● Base bridge mode: 802.1D transparent bridge
● Redundancy mechanism: Ring redundancy
Device Factory setting ring ports
SCALANCE XB208 and XB216 P0.1 and P0.2
SCALANCE XB205-3, XB205-3 (SC) and XB205-3LD (SC) P0.7 and P0.8
SCALANCE XB213-3, XB213-3 (SC) and XB213-3LD (SC) P0.15 and P0.16
● Trust mode: Trust CoS
● IGMP Snooping/IGMP Querier: Off
● IPv4 Address Collision Detection: Never give up
Type designation
The type designation of a SCALANCE XB-200 is made up of several parts that have the
following meaning:
Interface
Number of electrical connectors
Number of optical connectors
XB2 -
Interfaces of devices with optical connectors:
Interface Property
(SC) 10/100 Mbps SC port, multimode fiber-optic cable, up to 5 km
LD (SC) 10/100 Mbps SC port, single mode fiber-optic cable, up to 26 km
[-] 10/100 Mbps ST port, multimode fiber-optic cable, up to 5 km
Description of the device
4.1 Product overview
SCALANCE XB-200
18 Operating Instructions, 03/2020, C79000-G8976-C359-09
